Rated current: 4 A
Power consumption (typical): 10 W
DC input voltage: 12 V
Depth: 284 mm
Height: 56 mm
Package weight: 2.73 kg
Weight: 1.57 kg
Package depth: 141 mm
Package width: 433 mm
Package height: 366 mm
Width: 375 mm
Supported resolutions: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Video formats supported: H.265+, H.265, H.264+, H.264
Audio formats supported: G.711 μ-law, G.726, PCM, G.711 A-law
Video input channels: 32 channels
Alarm input channels: 4
Alarm output channels: 2
Multi-screen: Yes
Maximum resolution: 3840 x 2160 pixels
Number of HDDs supported: 2
HDD interface: SATA
Maximum storage capacity: 20 TB
Ethernet LAN data rates: 1000, 100, 10
Internal SATA ports quantity: 2
VGA (D-Sub) output ports: 1
USB 2.0 ports quantity: 1
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Audio RCA outputs: 1
Audio RCA inputs: 1
Number of USB 3.0 ports: 1
Warnings: The product must be disposed of properly in accordance with local regulations for the disposal of electronics., Do not expose the device to moisture or extreme temperatures.
