Built-in processor: Yes
Certification: CE EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014 CE LVD: EN 62368-1:2014 2023-09-26
Rack mounting: Yes
LED indicators: Yes
Product colour: White
Rack capacity: 1U
Output current: 1.5 A
Output voltage: 12 V
Operating relative humidity (H-H): 10 - 93%
Operating temperature (T-T): -10 - 55 °C
Package weight: 1.05 kg
Height: 45.6 mm
Package depth: 364 mm
Weight: 450 g
Depth: 206.4 mm
Package width: 96 mm
Width: 204.6 mm
Package height: 261 mm
Browser supported: Chrome IE 9 or later Firefox
Mobile operating systems supported: iOS, Android
Input bandwidth: 80 Mbit/s
Video codecs: Smart H.265+ H.265 Smart H.264+ H.264 MJPEG
Video recording modes: 2160p, 720p, 1024p, 1080p
Audio codecs: PCM G711A G711U G726
Video input channels: 4 channels
Output bandwidth: 60 Mbit/s
Operating system installed: Embedded LINUX
Playback modes: Pause, Play, Stop
Recording modes: Manual
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
HDMI output: Yes
Audio RCA outputs: 1
Ethernet LAN data rates: 100 Mbit/s, 10
Audio RCA inputs: 1
VGA (D-Sub) output ports: 1
HDMI ports quantity: 1
DC-in jack: Yes
Number of HDDs installed: 1
Maximum storage capacity: 20 TB
HDD interface: SATA
Warnings: The product must be disposed of properly in accordance with local regulations for the disposal of electronics., Do not expose the device to moisture or extreme temperatures.
