Warranty period: 5 year(s)
Country of origin: China
Lockable: Not lockable
Product colour: Black
Housing material: Steel
Weight: 8.72 kg
Depth: 138 mm
Width: 680 mm
Depth (max): 13.8 cm
Height: 3220 mm
Package height: 1270 mm
Package depth: 115 mm
Package width: 320 mm
Package weight: 10.2 kg
Tilt angle range: -25 - 0°
Height adjustment range: 2500 - 3000 mm
Cable management: Yes
Height adjustment: Yes
Pivot angle: -3 - 3°
Angle of rotation: 6°
Tilt adjustment: Yes
Swivelling: Yes
Rotating: Yes
Height adjustment type: Manual
Swivel angle range: -180 - 180°
Products per pallet (EU): 34 pc(s)
Master (outer) case gross weight: 10.2 kg
Master (outer) case width: 320 mm
Master (outer) case height: 1270 mm
Harmonized System (HS) code: 7326909890
Master (outer) case length: 115 mm
Products per master (outer) case: 1 pc(s)
Master (outer) case net weight: 10.2 kg
Maximum weight capacity (per display): 50 kg
Panel mounting interface: 440 x 400, 600 x 400 mm, 400 x 400 mm, 300 x 200 mm, 350 x 350, 300 x 300 mm, 500 x 400, 200 x 400, 300 x 100, 150 x 200, 400 x 200 mm, 200 x 150, 200 x 300, 600 x 300, 200 x 100 mm, 200 x 200 mm, 400 x 300 mm, 600 x 200
Maximum screen size: 177.8 cm (70 )
Mounting type: Ceiling
Minimum screen size: 94 cm (37 )
Minimum VESA mount: 150 x 200 mm
Maximum VESA mount: 600 x 400 mm
Number of displays supported: 1
Maximum weight capacity: 50 kg
